TheCC-Z4 cutting machine system is designed for medium-to-large cutting machinesand provides comprehensive flame/plasma cutting processes.
1.Large-size display interface: Four-torch independent control with a 15-inchLCD. Switchable and configurable user interface for clearer, more focuseddisplay. Supports every cutting process and adapts to complex workingenvironments.
2.More powerful industrial-grade embedded core: Processing speed is 4×that of the CC-Z3 CNC system. Advanced circular interpolation andacceleration/deceleration algorithms fully exploit the machine’scharacteristics, ensuring smooth, stable cutting.
3.Greater operating convenience: Equipped with a multifunctional knob, right-sideshortcut keys, menu hotkeys, and standard 4-torch control buttons for easieroperation. Comprehensive status indicators, operation prompts, parameterexplanations, and interface descriptions.
4.Support for multiple combined cutting and marking processes: Pre-loadedprocesses: plasma, flame, laser, scribing, drilling, etc. Enables combinedcutting processes and remains stable in complex electromagnetic environments.
BasicSpecifications
Processor:Industrial-grade ARM chip
Display:15-inch true-color LCD
I/O:32 opto-isolated inputs, 24 opto-isolated outputs
Axes:4 simultaneous axes, expandable to 6
AD/DA:2 ×DA, 2 × AD
Encoderinputs: 3 channels
PWMoutputs: 4 channels
Communications:2 ×RS-232, 1 × USB, 1 × RS-485
Pulseequivalent: Electronic-gear numerator/denominator range 1–65,535
Userstorage: 4 GB for user programs
Operatingtemperature: 0 °C to +40 °C
Storagetemperature: –40 °C to +60 °C
