Applicableto flame/plasma, high-pressure waterjet and laser cutting machines, widely usedin metal fabrication, advertising, stone processing and other industries.
●Powered by an industrial-grade ARM processor.
●16opto-isolated inputs and 16 opto-isolated outputs.
●Simultaneouslycontrols up to 2 axes, expandable to 4 axes.
●Electronicgear ratio: numerator & denominator adjustable from 1 to 65 535.
●User program storage: 16 MB – 32 MB.
●Operating temperature: 0 °C – +40°C.
●Storagetemperature: –40 °C – +60°C.
●High-reliability design: anti-plasma interference, lightning protection andsurge immunity.
●Practicalflame/plasma cutting technology: automatic corner-speed control and THC controlduring plasma cutting; wireless remote control supported.
●Kerf compensation with automatic verification and user-selectable alerts.
●Break-pointresume, auto power-failure recovery and automatic breakpoint memory.
●Arbitraryprogram-segment and pierce-point selection.
●Extended piercing for thick plates and bridge cutting for thin plates.
●Back-step, segment selection and optional pierce positions during breakpointrecovery for effortless operation.
●Cuttingcan be transferred at any time.
●Special micro-segment processing ensures smooth motion, ideal for metalblanking, advertising and ornamental ironwork.
●Partlibrary with 40+ shapes (expandable and customizable) covering common basicparts.
●Fullycompatible with nesting software such as StarCAM, FASTCAM, etc.
●Switchable Chinese/English interface, dynamic graphics display, 1×–8×zoom, automatic cursor tracking, program loading via USB drive and convenientsoftware upgrades.
